Product Description
Technical specification
Body | Model | TDM693Z |
Dimension | 1770×670×1130mm | |
Net weight | 102.3 kg | |
Standard load capacity | ≤150 kg (including the rider) | |
Standard max speed | 45 Km/h | |
Standard range per charge | 55~60 Km | |
Wheel specification | 10*3.5 integrated rim | |
(F/R tyre) Wheel base | 1,300 mm | |
Minimum Ground Clearance(mm)
| 175 | |
Tyre specification | 10*3.5 | |
Battery | Type | Free-maintenance sealed lead-acid battery |
Specification | 60V/20Ah | |
Motor | Type | DC brushless |
Rated output power | 1500~2000 watts | |
Rated output torque | 12N.m | |
Climb capacity | ≤15° | |
Controller | Controller model | 60V/35A-15T |
Under-voltage protection | 52.5±0.5V | |
Charger | Specification | 60V/3A |
Charging voltage | AC110~220V-50Hz or specified by the customer | |
Charging Time | 2—8 Hrs | |
Power consumption per charge | ≤0.7 kw.h | |
Brake | Type | F/R Disc/Drum brake |
Trading part
Price | FOB Shenzhen USD |
|
Payment term | By TT, 30% in advance to place the order, balance 70% to be paid before shipment |
|
Packing | Carton |
|
Container load capacity | 35 units in 1*20` container | 80 units in 1*40`HQ |
MOQ | 1*20`Container |
|
Delivery time | 15-25 days after the reception date of the 30% deposit |
|
The One And Only
ARS(Automatic Drive Failure Recovery System)
We adopt SIEMENS faults identifying system,which can intelligently test the brake circuit,throttle circuit,motor hall circuit and the voltage of the battery and then gives phonic alarm if the circuit goes wrong and gives a phonic indication of satarting the standby emergency system,in which the vehicle can continue working.This is the special technology of our company.
Company Information
THR SHOW OF OUR COMPANY
FAQ
FAQ
1.How can I get the production and price information?
Just contact us ,then we will send the information which
you need to you.
2.What’s the minimum order?
1*20GP.
3.How long does it take to receive the goods?
Object to different type of model and the quantity of your order.
4.What’s color are available?
We have many color options, such as black, red , white, yellow, blue, silver, orange and so on, so we can make the colors based on your request.
5.Can you deliver samples by DHL or FEDX?
The freight by DHL or FEDX is very expensive because our products contain battery .It usually costs more than the electric bike value, so we suggest you choose sea shipping.
6.Can you change configuration for me?
No problem, we can change configuration based on your request.
